White Plain Weave 0.2mm 7628 Electrical FIberglass Used For Electrical Insulation
1. Product Description:
This kind of fabric is an electronic glass fiber. It has good electrical properties. After being treated with a special silane coupling agent, the fabric can be combined with thermosetting resin such as epoxy resin. The result meets the heat resistance requirements of subsequent processes. In order to meet the requirements of multi-layer laminates in the CCL and FR4 industries, it has good dimensional stability..E-glass fiberglass fabric (cloth) is widely uesd in aircraft and spaceflight industry, ship industry, chemical industry, medicalindustry, military industry, sports goods, etc. It is available in manufacturing FRP fishing pole, golf pole, baseball pole, surfboard, sailboard, skis, ice stick, etc.
Table 1: E-Glass 7628 Product Description
| Material | 100% E-glass Fiberglass |
| Color | White |
| Thickness | 0.2mm |
| Weight | 200g/m2 |
| Width | 1.27m or Other sizes can be customized |
| Length | 50m,100m or Other sizes can be customized |
| Weave | Plain |
| Package | Carton box |
| Breaking Strength | 438*350N/cm |
| Yarn Type | EC9 68 1*0 |
Table 2: Related Industry and Electrical Fiberglass Fabric
| Type | Area Weight | Weave Structure | Warp and Weft Density |
| 2116 | 105 g/m2 | 3.1 oz/yd2 | Plain | 24*23/cm |
| 7628 | 200 g/m2 | 5.9 oz/yd2 | Plain | 18*10/cm |
| 3732 | 430 g/m2 | 12.7 oz/yd2 | Twill | 18*12/cm |
| 666 | 630 g/m2 | 18.6 oz/yd2 | Satin | 16*14.5/cm |
| 3784 | 880 g/m2 | 26 oz/yd2 | Satin | 18*12/cm |
| 3786 | 1000-1400g/m2 | 29.5-41.3 oz/yd2 | Satin | 16*13/cm |
| 3788 | 1650 g/m2 | 48.7 oz/yd2 | Satin | 18*13/cm |
2. Product Features:
- The E-glass fiber yarn is produced by the pool kiln method and is also produced by the sputum method.
- Flat fabric, uniform thickness, less filament
- Corrosion resistance, easy to infiltrate resin, good adhesion between layers,
- High tensile strength
- Excellent electrical insulation properties.
3. Application:
- Electric Insulation
- Non-metallic Compensator
- Anti-corrosion sector
- Used for weaving electronic cloth, electric insulating cloth and fishing rod cloth,
 | Electrical Grade Fiber Glass Cloth is an Important Material for PTFE Coated Glass Cloth and Other Coating Material |
 | With the Development of Internet, Specially Mobile, Electronic Products will be more Prosperous and booming Via the Market, CCL, PCB, Fiber Glass Cloth will be Getting Into Much Busy Market. |
5. High quality
The fiberglass yarns are supplied by our company, it has 10% more strength, much softer and more beautiful surface than normal product. Our company produces glass fiber yarn raw materials and the most advanced loom. Therefore, our glass fiber cloth quality is much better than other suppliers in China and faster production rate.
6. Package
We can provide you with 100-meter small rolls or 500-meter big rolls. Each roll has an independent carton package to protect the quality of the cloth during the shipping process.
